Bulldog is the premiere provider of sealing solutions for heavy equipment worldwide,offering hydraulic cylinder kits,hydraulic pump seal kits, hydraulic breaker seal kits,hydraulic breaker diaphragms and walking motor seal kits, rock drill seal kits.
| Place of Origin: | Guangzhou, China |
|---|---|
| Brand Name: | BULLDOG,NICEPARTS |
| Model Number: | KOMATSUKOMATSU Wb97 WB93S backhoe loader |
| Minimum Order Quantity: | 1set |
| Price: | Consultation by letter |
| Packaging Details: | Carton packaging |
| Delivery Time: | 3-10 Days After Payment received |
| Payment Terms: | T/T, Western Union, MoneyGram,Paypal,Alipay |
| Supply Ability: | 150set |
| Type: | KOMATSU KOMATSU Wb97 WB93S Backhoe Loader ARM LIFTING Seal Kits | Material: | PU+NBR+PTFE |
|---|---|---|---|
| Color: | Black+Blue+yellow | For: | KOMATSU Hydraulic System |
| Quality: | High-Quality | Rod: | 45mm |
| Piston: | 70mm | Condition: | 100%new |
| Stock: | In Stock | Model: | Komatsu Backhoe Loader |
| Highlight: | Komatsu Hydraulic Cylinder Seal Kits,Wb93s Hydraulic Cylinder Seal Kits,707-99-15730 backhoe cylinder seal kits |
||
Parts list
NO. |
PART NO. | DESCRIPTION | Q'TY |
| 707-00-0Y920 | CYLINDER, ASSY. | 1 | |
| 1 | 707-76-45550 | BUSHING | 1 |
| 2 | 721-58-45600 | PISTON ROD | 1 |
| 3 | 07179-12057 | RING, WEAR | 1 |
| 4 | 707-29-70641 | CYLINDER HEAD | 1 |
| 5 | 707-52-90210 | BUSHING | 1 |
| 6 | 707-36-70620 | PISTON | 1 |
| 7 | 707-67-33010 | NUT | 1 |
| 8 | 707-11-70A20 | CYLINDER | 1 |
| 9 | 07144-10505 | BUSHING | 1 |
| 707-99-15730 | KIT, GASKET | 1 | |
| 10 | 112-63-15370 | SEAL | 1 |
| 11 | 07000-12070 | O-RING | 1 |
| 12 | 707-51-45030 | GASKET | 1 |
| 13 | 707-51-45640 | GASKET | 1 |
| 14 | 07000-12065 | O-RING | 1 |
| 15 | 07146-02066 | RING, WEAR | 1 |
| 16 | 07156-00710 | PACKING ROD | 2 |
| 17 | 707-44-70110 | GASKET | 1 |
| 18 | 02896-11012 | O-RING | 2 |
| 19 | 21D-09-89300 | FITTING, GREASE | 1 |
| 20 | 21D-09-89140 | GREASE NIPPLE | 1 |
Parts exploded view
More service models
| WB140-2 | ||||||
| B/H ARM | 395002005 | 60 mm | 110 mm | KOM-878000490 | ||
| B/H BOOM | 395001007 | 60 mm | 120 mm | KOM-878000489 | ||
| 395001009 | 60 mm | 120 mm | KOM-878000489 | |||
| B/H BOOM SWING LH | 395005010 | 50 mm | 115 mm | KOM-878000542 | ||
| 395005018 | 50 mm | 115 mm | KOM-878000542 | |||
| 707-02-11510 | 50 mm | 115 mm | KOM-707-98-33500 | |||
| 707-02-11510 | 50 mm | KOM-07177-05030 | ||||
| B/H BOOM SWING RH | 395005009 | 50 mm | 115 mm | KOM-878000542 | ||
| 395005017 | 50 mm | 115 mm | KOM-878000542 | |||
| 707-02-11520 | 50 mm | 115 mm | KOM-707-98-33500 | |||
| 707-02-11520 | 50 mm | KOM-07177-05030 | ||||
| B/H BUCKET | 395003003 | 60 mm | 95 mm | KOM-878000492 | ||
| 395003005 | 60 mm | 95 mm | KOM-878000492 | |||
| B/H OUTRIGGER LH | 395011005 | 55 mm | 110 mm | KOM-878000494 | ||
| 395011008 | 55 mm | 110 mm | KOM-878000494 | |||
| B/H OUTRIGGER RH | 395011006 | 55 mm | 110 mm | KOM-878000494 | ||
| 395011007 | 55 mm | 110 mm | KOM-878000494 | |||
| B/H TELESCOPIC ARM | 395009001 | 40 mm | 70 mm | KOM-878000388 | ||
| 395009006 | 40 mm | 70 mm | KOM-878000388 | |||
| L/S BOOM | 395012014 | 50 mm | 85 mm | KOM-878000486 | ||
| 707-00-80C10 | 50 mm | 80 mm | KOM-707-98-25090 | |||
| 707-00-80C10 | 50 mm | KOM-07177-05030 | ||||
| L/S BUCKET | 395013017 | 50 mm | 80 mm | KOM-878000487 | ||
| 707-00-85080 | 50 mm | 85 mm | KOM-707-98-25830 | |||
| 707-00-85080 | 50 mm | KOM-07177-05030 | ||||
| L/S BUCKET LH | 395013017 | 50 mm | 80 mm | KOM-878000487 | ||
| L/S BUCKET MP | 312230674 | 45 mm | 80 mm | KOM-827020113 | ||
| L/S BUCKET QC | 200060282 | 18 mm | 30 mm | KOM-42N-879-1980 | ||
| L/S BUCKET RH | 395013019 | 50 mm | 80 mm | KOM-878000487 | ||
| OUTRIGGER LH | 721-00-11540 | 55 mm | 110 mm | KOM-707-98-34460 | ||
| 721-00-11540 | 55 mm | KOM-07177-05530 | ||||
| OUTRIGGER RH | 721-00-11550 | 55 mm | 110 mm | KOM-707-98-34460 | ||
| 721-00-11550 | 55 mm | KOM-07177-05530 | ||||
Company warehouse
FAQ
1. Q: Are you a manufacturer or trader?
A: We are both in manufacturer and trader, have more than 10 years
of industry experience.
2. Q: Can i make a small order first?
A: Yes, of course.
3. Q: If we let the product make a change of the size, can you offer the
seal kit for this size?
A: Yes, just send the machine model, part number and the change
of size to us, we can make it.
4. Q: Have you support the OEM or not?
A: Sure, we support the OEM,BULLDOG or as required.
5. Q: How can i pay the goods?
A: For the payment, we support the PayPal, Western Union, Money Gram, T/T in advance, L/C at sight, etc
6. Q: How to ship the products?
A: For the shipment, we support the DHL Fedex EMS UPS or by Air/ Sea., if you have the agent in china, we can contact your agent according to your request.
7. Q: What’s the delivery time?
A: The goods can be shipped at 2-5 working days after receiving payment.
